DimensionReceiver:209x142.5x28.5mmOutdoorsensorWS90:93*93*208mmFeatures1.7.5’LargeLCDscreen.2.
Dimension
Receiver: 209x142.5x28.5mm
Outdoor sensor WS90: 93*93*208mm
Features
1. 7.5’ Large LCD screen.
2. WiFi capable: enables your station to publish its data wirelessly to weather servers: Ecowitt.net, Weathercloud, Wunderground, WOW or third part server. Easy integration to 3rd party system. And view the current weather condition directly via our weather app.
3. Indoor temperature, humidity, air pressure measured by display console in-built sensor
4. Wireless Outdoor Solar Powered 7-in-1 Weather Sensor measures temperature, humidity,wind speed, wind direction, rainfall,light and UV.
5. 7-in-1 sensor WS90 with no moving parts, Near-zero maintenance
6. Solar power supply providing energy support for extended unmanned operations
7. Supports receiving and display up to 8 outdoor temperature & humidity sensor (optional)
8. Support receiving and displaying CO2, PM1.0, PM2.5, PM10 and AQI data from air quality sensor (optional).
9. Can paired with up to 16 IoT Devices (WFC01 smart water timers/AC1100 smart plugs) to enable remote control through the Ecowitt app.
10. Support over 49 sensors uploading data to ecowitt weather server. Combined with the Ecowitt app, WSView Plus app and Ecowitt.net, you will get a more powerful data service function.
11. Weather forecast, moon phase, sunrise/sunset
12. Global time synchronization while base station connected with the internet
13. 5 levels of brightness adjustment: Max/High/Medium/Low/Off
14. Data storage on Ecowitt server: https://ecowitt.net
15. Time Alarm/Snooze
Specifications
|
Specification |
Indoor Temperature range |
-9.9°C – 60°C |
Outdoor Temperature range |
-40°C – 60°C |
Temperature accuracy |
±1°C |
In/Outdoor Humidity range |
1% ~ 99% |
Humidity accuracy |
±5% |
Barometric pressure range |
300 – 1,100 hPa (8.85 – 32.5 inHg) |
Barometric pressure accuracy |
± 5 hPa in 700 – 1,100 hPa range |
Rain range |
0-9999mm |
Rain accuracy |
±20%(<5mm/h) ±10% (5mm/h~50mm/h) ±20% (>50mm/h) |
Wind Speed range |
0-40m/s |
Wind Speed accuracy |
+/- 1m/s (wind speed< 10m/s) +/-10% (wind speed > 10m/s) |
Light |
0 - 200Klux |
Transmission range |
150meter |
Sensor reporting interval |
8.8 seconds |
Alarm Duration |
120 seconds |
Power |
Specification |
Base station/console |
5V 1A DC Adapter (a USB to 2.5*0.7mm DC 5V power plug connector cable included) |
Outdoor sensor |
Solar panel (built-in) 6.5V/4mA |
Outdoor sensor (backup) |
2 x AA 1.5V battery (not included) |
