1. Built-in NDIR sensor and Particle sensor
2. Tracks CO₂, PM1.0, PM2.5, PM4.0, PM10, temperature, and humidity
3. Wireless device
Built-in Sensors:
Features Switzerland Sensirion NDIR Sensor and Micro Laser Particle Sensor for precise monitoring.
• Comprehensive Monitoring:
Tracks CO₂, PM1.0, PM2.5, PM4.0, PM10, temperature, and humidity, all displayed on a clear screen.
• Sampling Frequency:
Samples every 60 seconds when powered by USB and every 10 minutes on battery power.
• Indoor Use:
Designed for indoor environments with a USB power connection.
• Air Quality Index:
Displays air quality in six grades, indicating different air conditions.
• Data Upload:
Pair with our WiFi Gateway or Console display (sold separately) to upload data to the weather server and view it on an app and website.
Technical Specifications
Dimension: 106×68×69mm
Power: AC power (5V 1A) - Not included
2 x AA 1.5V Batteries for back up – Not Included
Update Interval: About 1 minute
Automatic cleanup interval: 2 days
RF Frequency: 920/915/868/433MHz (depending on local regulations)
RF Wireless Range: 100 meters (in open areas)
|
measurement |
Range |
Accuracy |
Resolution |
|
PM1.0 & PM2.5 |
0 ~ 1000 ug/m³ |
0~100ug/m³, ±【5ug/m³+5%】 100~1000ug/m³, ±10 % |
1 ug/m³ |
|
PM4.0 & PM10 |
0 ~ 1000 ug/m³ |
0~100ug/m³, ±25 ug/m³ 100~1000ug/m³, ±25 % |
1 ug/m³ |
|
CO2 |
0 to 40000 ppm |
400 ~ 2000 ppm, ±(50 ppm + 5% of reading) Accuracy drift per year, ± (5ppm + 5% of reading) |
1ppm |
|
Temperature |
-10°C ~ 60°C |
±0.8°C when 15°C to 35°C |
0.1°C |
|
Humidity |
1% ~ 99%RH |
± 6%RH when 15°C to 35°C Accuracy drift per year < 0.25%RH |
1%RH |
